| الاسم التجاري: | TICO |
| رقم الطراز: | اس تي سي-TMJ-200 |
| الـ MOQ: | 1 مجموعة |
| السعر: | قابل للتفاوض |
| وقت التسليم: | 20 ~ 30 يوما |
| شروط الدفع: | تي/تي |
Slot Extrusion Roll to Roll Coating Machine Used in Glovebox
Product Introduction
This product is equipped with a slot-die coating head and a precision syringe pump feeding system, enabling non-contact coating on substrates using the slot-die extrusion coating head for the coating process of lithium battery cathode and anode electrodes. It is also suitable for coating processes of other types of slurry and substrates. The equipment offers high coating precision, good consistency, and stability. It can be used in industries such as lithium batteries, FCCL, optical films, high-end tapes, and various functional films. It is ideal for process development in laboratories or pilot lines.
Key Features
● The drying oven is made of stainless steel, featuring corrosion resistance and an attractive appearance; it is also compact in size and can be placed inside a glove box for use.
● Slot extrusion coating with high precision and good consistency.
● Closed slurry operation, free from external parameter interference.
● Die head is made of SUS630 stainless steel, strong adaptability and corrosion resistance.
● The winding & unwinding device is equipped with a deviation correction device, and the substrate is under tension control, which prevents substrate misalignment and ensures stable material travelling.
● Heating with digital temperature controller, independent high-precision PID temperature control mode; infrared heating tube ensures uniform drying of materials.
● PLC control with HMI operation, convenient and user-friendly.
Technical Parameter
| Model | STC-TMJ-200 |
| Voltage | AC220V±10%, 50Hz |
| Power | 4KW |
| Coating method | Slot extrusion coating |
| Syringe pump processing capacity | 1L per batch |
| Roller width | 230mm |
| Coating width | Max.200mm |
| Coating speed | 0 ~ 0.5m /min (depending on drying condition) |
| Single side coating thickness after drying | 10~200μm |
| Coating accuracy | ±3μm |
| Max bearing capacity of air inflatable shaft | 30kg |
| Dimension |
L1650 * W700 * H520mm (Oven lid opened total height is H650mm) |
| Weight | 250kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
